Products
Lazerlite Premium Turbo Ventilators
| LAZERLITE 24" ALU TURBINE TECHNICAL SPECIFICATIONS | |
|---|---|
| Material Used: | Totally Aluminium Built |
| Number of Vanes: | 0.47 mm thickness, 38 Numbers Centre |
| Shaft: | Stainless Steel |
| Bearing: | 2 No’s Self Lubricate Sealed |
| Rivets: | Aluminium Pneumatic Rivets |
| Turbine Doom Thickness: | 1 mm (Stainless Steel) |
| Turbine Outer Dia: | 680 mm |
| Turbine Doom Dia: | 380 mm |
| Turbine Rotor Dia: | 655 mm (Stainless Steel) |
| Turbine Throat Dia: | 610 mm |
| Turbine Height: | 230 mm |
| Turbine Weight: | 4 Kgs |
| 24" Stainless Steel Mirror Finish Turbine Technical Specifications | |
|---|---|
| Material Used: | Totally Stainless Steel Built |
| Number of Vanes: | 0.3 mm thickness, 38 Numbers |
| Centre Shaft: | Stainless Steel |
| Bearing: | Self Lubricated - 2 Nos |
| Rivets: | Aluminium Pneumatic Rivets |
| Turbine Doom Thickness: | 1mm Stainless Steel |
| Turbine Outer Dia: | 686 mm |
| Turbine Doom Dia : | 380mm |
| Turbine Rotor Dia: | 655 mm |
| Turbine Throat Dia: | 610mm |
| Turbine Height: | 360 mm |
| Turbine Weight: | 4.6 Kgs |
